| Model | PV 14000 |
|---|
| Rated Power | 10KVA / 10KW |
| Running Motor Capacity | 1.5P + 3P |
| Phase | 1-Phase In / 1-Phase Out |
| Maximum PV Input Power | 4500W x 3 |
| GRID-TIED Operation | |
|---|
| PV INPUT (DC) | |
|---|
| Maximun DC Voltage | 500Vdc |
| Start-up Voltage | 90Vdc |
| MPPT Voltage Range | 60-450Vdc |
| Number of MPPT Trackers / Maximum Input Current | 3 / 18A |
| GRID OUTPUT (AC) | |
|---|
| Nominal ut Voltage | 20 / 230 / 240 VAC |
| Output Voltage Range | 195.5 – 253 VAC |
| Nominal Output Current | 43.5 A |
| Power Factor | > 0.99 |
| EFFICIENCY | |
|---|
| Maximum Conversion Efficiency (DC/AC) | 97% |
| OFF-GRID OPERATION | |
|---|
| AC INPUT | |
|---|
| AC Start-up Voltage / Auto Restart Voltage | 170 – 280 VAC / 180 VAC (UPS0) |
| Acceptable Input Voltage Range | 90-280 VAC (APL) or 170-280 VAC (UPS) |
| Frequency Range | 50 Hz / 60 Hz (Auto Sensing) |
| Maximum AC Input Current | 43.5 A |
| GENERAL | |
|---|
| PHYSICAL | |
|---|
| Dimension, D x W x H (mm) | 360.7 x 310 x 107.3 |
| Net Weight (kg) | 6.6 |
| INTERFACE | |
|---|
| Communication Port | PS232 / Wi-Fi |
| ENVIORNMENT | |
|---|
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| IP Degree | IP21 |
| Operating Temperature (°C) | -10 ~ 50 |
| Storage Temperature (°C) | -15 ~ 60 |
