| Model | VOLTRON G6 |
|---|
| Phase | 1-Phase In / 1-Phase Out |
| Maximum PV Input Power | 4500W + 4500W |
| Rated Output Power | 6000W |
| Maximum Charging Power | 6000W |
| GRID-TIED Operation | |
|---|
| PV INPUT (DC) | |
|---|
| Maximun DC Voltage | 520Vdc |
| Start-up Voltage / Initial Feeding Voltage | 90Vdc / 120Vdc |
| MPPT Voltage Range | 50Vdc-500Vdc |
| Number of MPPT Trackers / Maximum Input Current | 2 / 18A |
| GRID OUTPUT (AC) | |
|---|
| Nominal ut Voltage | 220 / 230 / 240 VAC |
| Output Voltage Range | 184 – 264.5 VAC or 195.5 – 253 VAC or 184 – 264.4 VAC (Selectable) |
| Nominal Output Current | 26.1 A |
| Power Factor | > 0.99 |
| EFFICIENCY | |
|---|
| Maximum Conversion Efficiency (DC/AC) | 97% |
| OFF-GRID OPERATION | |
|---|
| AC INPUT | |
|---|
| AC Start-up Voltage | 170VAC – 280 VAC |
| Acceptable Input Voltage Range | 90-280 VAC (APL) or 170-280 VAC (UPS) |
| Frequency Range | 50 Hz / 60 Hz (Auto Sensing) |
| Maximum AC Input Current | 35 A |
| PV Input (DC) | |
|---|
| Maximum DC Voltage | 520Vdc |
| MPPT Voltage Range | 50Vdc – 500Vdc |
| Number of MPPT Trackers / Maximum Input Current | 2 / 18 A |
| Battery Mode Output (AC) | |
|---|
| Nominal Output Voltage | 220 / 230 / 240 VAC |
| Output Waveform | Pure Sine wave |
| Efficiency (DC to AC) | 93% |
| HYBRID OPERATION | |
|---|
| PV Input (DC) | |
|---|
| Maximum DC Voltage | 520Vdc |
| Start-up Voltage / Initial Feeding Voltage | 90Vdc – 12Vdc |
| MPPT Voltage Range | 50Vdc – 500Vdc |
| Number of MPPT Trackers / Maximum Input Current | 2 / 18 A |
| Grid Output (AC) | |
|---|
| Nominal Output Voltage | 220 / 230 / 240 VAC |
| Output Voltage Range | 184 – 264.5 VAC or 195.5 – 253 VAC or 184 – 264.4 VAC (Selectable) |
| Nominal Output Current | 26.1A |
| AC Input | |
|---|
| AC Start-up Voltage | 170VAC – 280 VAC |
| Acceptable Input Voltage Range | 90-280 VAC or 170-280 VAC |
| Maximum AC Input Current | 35A |
| Battery Mode Output (AC) | |
|---|
| Nominal Output Voltage | 220 / 230 / 240 VAC |
| Efficiency (DC to AC) | 93% |
| Battery & Charger | |
|---|
| Nominal DC Voltage | 48Vdc |
| Maximum Solar Charging Current | 125A |
| Maximum AC Charging Current | 125A |
| Maximum Charging Current | 125A |
| GENERAL | |
|---|
| Physical | |
|---|
| Dimension, D x W x H (mm) | 493 x 499 x 200 |
| Net Weight (kg) | 18.7 |
| Interface | |
|---|
| Parallel Function | Yes, 6 Units |
| Communication Port | RS485 / CAN / WiFi / Dry Contact |
| Enviornment | |
|---|
| Humidity | 5% to 95% Relative Humidity (Non-condensing) |
| IP Degree | IP65 |
| Operating Temperature (°C) | -10 ~ 50 |
| Storage Temperature (°C) | -15 ~ 60 |
